Use
Computer controlled hydraulic servo compression testing machine is mainly used to test compression strength of cement, concrete, rocks, brick. Space adjusting and  test processes could be controlled by the software and the test result could be transferred to the software in the computer for further analysis. It is the most advanced series in hydraulic compression testing machines. It is widely used in different steel works, engineering areas, quality control department, Universitiesand institutes as well as other areas and works.

Fully computer controlled testing process. Stable and reliable high intensity structure load frame. Real time display software will provide accurate track of testing process. Powerful multifunctional control software will provide more testing methods and standards.

Specification:

STYE-2000P
Max. Testing power: 2000kN
Measuring range: 0-2000kN
Relative indication error: ±1%
Max. distance between the up and down bearing plates: 310mm
Max. piston stroke: 300mm
Diameter of the piston: Φ250mm
Rated pressure of the hydraulic pump: 40MPa
Power: AC380 or AC220V±10%
Main frame: 600×600×2000mm
Control console: 1050×650×860mm
Max. piston lift speed: 50mm/min.
Piston free back speed: 20mm/min.
Net weight: about 1650kgs
Noise: ≤80Db

STYE-3000P
Max. Testing power: 3000kN
Measuring range: 0-3000kN
Relative indication error: ±1%
Max. distance between the up and down bearing plates: 380mm
Max. piston stroke: 300mm
Diameter of the piston: Φ310mm
Rated pressure of the hydraulic pump: 40MPa
Power: AC380 or AC220V±10%
Main frame: 600×600×2240mm
Control console: 1050×650×860mm
Max. piston lift speed: 50mm/min.
Piston free back speed: 20mm/min.
Net weight: about 2250kgs
Noise: ≤80Db
